Minebea is to Launch 42 mm Square Hybrid Type Stepping Motors
Resource from: Minebea Co., Ltd. Likes:218
Oct 31,2012
~ New Design! Magnet with No Rare-Earth Element Content Realizes High Torque and High-Speed Followability Characteristics ~
Minebea Co., Ltd. (hereafter referred to as "Minebea") will launch its "Newly designed, high-torque, hybrid stepping motor" on October 30. This motor (size 42 mm square, stepping angle 1.8°: hereafter, high-torque 42 mm square HB motor) provides high torque via powerful magnets (hereafter called "non-rare earth magnets") having high magnetic force yet that do not use rare-earth metals such as neodymium or dysprosium.
Typical motors realize high torque by utilizing a neodymium sintered magnet which has the most powerful magnetism among permanent magnet types. However, this newly designed high-torque 42 mm square HB motor delivers motor torque equal or greater than neodymium sintered magnets by using powerful non-rare earth magnets as a substitute not requiring rare-earth metals such as neodymium.
In recent years, due to a drastic rise in price as well as anxiety over stable supply of neodymium and dysprosium, which are the raw material for neodymium sintered magnets, we, Minebea, have developed high-performance, high-torque motors using substitute magnets that use no rare earth materials. By switching over to non-rare earth magnets from here onwards we will secure a stable raw material supply and provide a stable supply of our products while lowering costs at the same time.
Features of the high-torque 42 mm square HB motor
1. Realized high torque by using non-rare earth magnets!
2. Newly designed internal structure & rotor, and stator gear profile!
•To develop this hybrid stepping motor, we made use of its massive store of magnetic field analysis data and various types of simulation software. A newly designed "rotor" and "stator gear profile" are what enabled us to provide ideal magnetic efficiency even while using non-rare earth magnets!
•Optimizing the internal structure design realized high-speed followability at a torque higher than that of neodymium sintered magnets.
3. Resource-saving design! Uses one less magnet as well as 25% less copper wire
•The high-torque 42 mm square HB motor utilizes a newly designed internal structure that delivers with only one non-rare earth magnet, the same or higher torque than two ordinary neodymium sintered magnets.
•Moreover, the copper wiring (magnet wire) quantity has been cut to 25% less than that of older Minebea products in a resource-saving design that drastically cuts down on material usage.
High-torque 42 mm square HB stepping motor
Launching : October 30, 2012
Price : Please contact us or our dealer.
Reference
Torque characteristics
Graph comparing torque characteristics of new 42×48 mm square model (17PM-F4xx) with conventional 42×48 mm square model (17PM-J4xx)
Sales Inquiries: Stepping Motor Product Sales Management
E-mail jpslhbstdinfo@m-mmotor.com
Media Inquiries: Minebea Co., Ltd.
Corporate Communications Office
TEL 81-3-5434-8637 FAX 81-3-5434-8607
High-torque 42 mm square HB stepping motor
Launching : October 30, 2012
Price : Please contact us or our dealer.
Reference
Torque characteristics
Graph comparing torque characteristics of new 42×48 mm square model (17PM-F4xx) with conventional 42×48 mm square model (17PM-J4xx)
Sales Inquiries: Stepping Motor Product Sales Management
E-mail jpslhbstdinfo@m-mmotor.com
Media Inquiries: Minebea Co., Ltd.
Corporate Communications Office
TEL 81-3-5434-8637 FAX 81-3-5434-8607
(Minebea Co., Ltd.)
