Kindly and urgently assist with a quotation for the SUPPLY & DELIVERY OF COAL FEEDER DRIVE SPROCKETS as quantified below and to the attached specifications:
NO:
ITEM
DESCRIPTION
Qty
Unit 2
Total
1
Coal Feeder Scrapper Chain Drive sprocket.
Dimensions: (see attached drawing for further details)
Overall Diameter: 320mm
Sprockets Diameter: 300mm
Outside Sleeve Diamater:185mm
Inner Sleeve Diameter: 140mm
Keyway dimensions: See Drawing
(Sprocket to be precision-machined and induction-hardened at teeth flank with Keyway cut out)
