Machining an eccentric shaft involves turning a cylindrical workpiece with an off-center axis. To ensure that the axis of the eccentric part coincides with the main axis of the lathe, you need to follow a series of steps and use proper techniques. Here's a general guide:
1.Mounting the Workpiece:
Securely mount the raw material (usually a cylindrical rod) in the lathe chuck or collet. Ensure that the workpiece is held firmly and concentrically to the lathe axis.
2.Center Drilling:
Before creating the eccentric feature, start by center drilling both ends of the workpiece. This will provide reference points for subsequent operations.
3.Turning the First End:
Turn and face one end of the workpiece to create a flat, perpendicular reference surface. This surface will be used for subsequent measurements.
4.Measuring and Marking:
Use a dial indicator or another precision measuring tool to find the exact center of the turned end. This center will be your reference point for creating the eccentric feature.
5.Calculating Eccentricity:
Determine the required eccentricity or offset from the center. This is the distance by which you want the eccentric feature to deviate from the central axis.
6.Setting Lathe Tools:
Adjust the lathe tools based on the calculated eccentricity. Move the cutting tool away from the center by the determined offset.
7.Turning the Eccentric Feature:
Carefully turn the eccentric feature by cutting material from the opposite side of the initial facing operation. Ensure that the tool is properly set to achieve the desired eccentricity.
8.Frequent Measurements:
Regularly measure the eccentric feature using a dial indicator or another measuring device. Make adjustments as needed to maintain accuracy.
9.Finishing Operations:
Complete any additional turning or machining operations on the eccentric shaft while ensuring that the eccentric feature remains accurately aligned.
10.Quality Checks:
Perform quality checks to verify that the axis of the eccentric part coincides with the main axis of the lathe. This may involve measuring concentricity and other dimensional tolerances.
Throughout the process, it's crucial to work carefully, make precise measurements, and adjust the lathe tools as needed. It may be beneficial to use specialized fixtures or tooling designed for eccentric turning to ensure accuracy. Additionally, consider the material properties and cutting conditions to avoid issues such as vibration or deflection during machining.
